A Fruit Feeder Machine is a vital piece of industrial food processing equipment used to consistently incorporate solid ingredients such as fresh, frozen, or candied fruits, nuts, chocolate chips, and candies into a continuous flow of a base product like ice cream or yogurt.

SS Hopper With Mixer
Accurate Ingredient Dosing
CIP Ready • SS304 Food Grade

Features & How It Works

Fruit Feeder Features

  • Blades made from special German Silver
  • All contact parts in SS 304 and food grade material
  • Separate drive for rotor and ingredient feeder
  • Easily connects with CIP system for quick cleaning
  • SS hopper with mixer for hygienic ingredient storage
  • Easy access and operation with PLC control

How It Works

  • Storage: Ingredients are held in a hygienic stainless steel hopper with mixer to prevent clumping
  • Dosing: A variable-speed rotor, screw, or piston meters the measured ingredient flow into the line
  • Mixing/Incorporation: Ingredients enter the main product stream and blend through an inline static mixer for uniform distribution



Orange & White Responsive Table (No Animations)
Technical Specification Data
Model Specification Table
Model F.F-200 F.F-400
Ice cream flow rate l/hr. 100 – 200 200 – 400
Augur motor (H.P) 0.5 H.P 0.5 H.P
Rotor motor (H.P) 1.0 H.P 1.5 H.P
Mixer motor (H.P) – 1 H.P
Hopper capacity, liter 10.0 25.0
Ingredient feeder rate, kg/hr. 05 – 30 20 – 80
